modena horizontal aluminium radiator <br/> colour shown RAL 9016
modena horizontal aluminium radiator
colour shown RAL 9016

modern minimalist die cast and extruded aluminium radiators
suitable for low temperature systems with ground or air source heat pumps
bottom side connections

  • aesthetic, efficient and environmentally friendly
  • very quick response time, versatile and large range
  • gentle lines easy on the eye, unlike many other aluminium radiators on the market
  • stock sizes in white (RAL 9016) available in 2 days
size
sections
output
stock code
price
(RAL 9016)
heightwidthwattbtu
 430 340  4   368  1256
falh4h4s
   96.00
 430  500
  6   552 1884falh4h6s 144.00
 430 660  8   736 2512falh4h8s 192.00
 430 820 10    920
 3139  falh4h10s  240.00
 430 980  12
  1104
 3767   falh4h12s
  288.00
 4301220
  15
 1380 4709  falh4h15s  360.00

580  340   4  4841652falh5h4s  100.00
580   500   6  7262478falh5h6s 150.00
580   660   8  9683304falh5h8s 200.00
580   820 1012104130  falh5h10s 250.00
580   980 1214524956  falh5h12s 300.00
580 1220 1518156195  falh5h15s 375.00

680  340   4  5521884falh6h4s   112.00
680   500   6  8282826falh6h6s 168.00
680   660   811043768falh6h8s 224.00
680   820 1013804710  falh6h10s 280.00
680   980 1216565652  falh6h12s 336.00
680 1220 1520707065  falh6h15s 420.00

780340   4  6322156falh7h4s 128.00
780 500   6  9483234falh7h6s 192.00
780 660   812644312falh7h8s 256.00
780 820 1015805390  falh7h10s 320.00
780 980 1218966468  falh7h12s 384.00

880340   4  6922360falh8h4s 152.00
880 500   610383540falh8h6s 228.00
880 660   813844720falh8h8s 304.00
880 820 1017305900  falh8h10s 380.00
modena range INFORMATION
EN442 OUTPUTS ΔT50C
FACTOR TO ΔT60C = 1.2675
ALL PRICES SUBJECT TO VAT

  TECHNICAL SPEC
Aluminium Made in Italy s days free delivery 5 Year Guarantee
DIMENSIONS - Modena Horizontal
Size nominal:   Actual width = (No. sections x 80mm) + 20mm
Back wall to front of rad
Back wall to pipe centres
Depth of rad
120mm
  75mm
  90mm
