modena flat aluminium radiator <br> colour shown RAL 9016
modena flat aluminium radiator
colour shown RAL 9016
modena flat aluminium radiator
modena flat aluminium radiator

modern minimalist die cast and extruded aluminium radiators
suitable for low temperature systems with ground or air source heat pumps
bottom side connections

  • aesthetic,efficient and environmentally friendly
  • very quick response time, versatile and large range
  • stock sizes in white (RAL 9016) available in 2 days
size
sections
output
stock code
price
(RAL 9016)
heightwidthwattbtu
430   340  4  372
1269faltf4h4s  96.00
430   500  6  5581904faltf4h6s 144.00
430   660  8  7442539faltf4h8s 192.00
430   82010  9303173  faltf4h10s 240.00
430   9801211163808  faltf4h12s 288.00
430 12201513954760  faltf4h15s 360.00


880  340   4  7282484faltf8h4s 152.00
880   500   610923726faltf8h6s 228.00
880   660   814564968faltf8h8s 304.00
880   820 1018206210  faltf8h10s 380.00
modena range INFORMATION
EN442 OUTPUTS ΔT50C
FACTOR TO ΔT60C = 1.2675
ALL PRICES SUBJECT TO VAT

  TECHNICAL SPEC
 Aluminium Made in Italy s days free delivery 5 Year Guarantee

DIMENSIONS - modena flat
Size nominal:   Actual width = (No. sections x 80mm) + 20mm
Back wall to front of rad
Back wall to pipe centres
Depth of rad
120mm
  72mm
  95mm
APOLLO pdf downloads
  • elegance and style brochure download
  • 131-Modena Flat Specification Sheet New.pdf Download
