rimini wave tube designer radiator <br> colour shown RAL 9016
rimini wave tube designer radiator
colour shown RAL 9016
contemporary vertical and horizontal designer radiators

vertical side entry
horizontal bottom entry

  • very versatile, can be mounted either vertically or horizontally
  • slim, sleek 16mm tubes
  • ideal for most settings
  • available in white(RAL 9016) in 2 days
  • a range of colours are available to order within 10 working days (vertical only)
RIMINI WAVE SINGLE WHITE
Size
tubes
Output
price white
(RAL 9016)
stock code
single white
Apollo
colours
heightwidthwattbtu
180030010  6142095375.00rww18h10t506.25
1800 5001811053770525.00rww18h18t708.75

RIMINI WAVE SINGLE CHROME
Size
tubes
Output
price chrome
stock code
single chrome
Apollo
colours
heightwidthwattbtu
1800300104911675  600.00rwc18h10tn/a
1800 400146882347  775.00rwc18h14tn/a
1800 5001888430161050.00rwc18h18tn/a

DIMENSIONS - RIMINI VERTICAL
Size nominal:   Actual width = (No. tubes x 28mm)
Back wall to front of rad
Back wall to pipe centres
Distance between tappings
        125mm max.
55mm
(No. tubes x 28mm)
N.B. The rimini radiator can also be mounted horizontally, in white or chrome (not colours)
(Please specify as a different bracket set is required)
DIMENSIONS - RIMINI HORIZONTAL
Size nominal:   Actual width = (No. tubes x 28mm)
Back wall to front of rad
Back wall to pipe centres
Distance between tappings
        110mm max.
70mm
Width of Rad Less 50mm
RIMINI RANGE INFORMATION
EN442 OUTPUTS ΔT50C
FACTOR TO ΔT60C = 1.2675
ALL PRICES SUBJECT TO VAT

  TECHNICAL SPEC
EXAMPLE RAL STOCK CODE
RAL7024_RWW18H10T
Steel Made in Italy s days free delivery  5 Year Guarantee
